Dovetail Slot Ties
Documents: 1 - 7 of 9
PRO-SLOT™ Anchor Slot is a stay-in-place concrete form used in forming a channel into the face of any poured wall or column. By installing Dovetail Anchors into the PRO-SLOT™, you can then anchor brick, block, or stone fascia to the poured surface. A Dovetail Triangular Tie is used to anchor masonry to concrete with the #1304 dovetail slot or with a wedge anchor.
sds sds sds| add | TYPE | VIEW DOCUMENT |
|---|---|---|
| folder | Submittal | link Dovetail Triangle |
| folder | Submittal | link Seismic (Metal Clip) |
| folder | SDS | link Stainless Steel |
| folder | SDS | link Bright Basic Wire |
| folder | SDS | link Galvanized Sheet Steel |
| folder | SDS | link Hot Dip Galvanized |
| folder | SDS | link Mill Galvanized |
In category:
Dovetail Triangular Tie 2102
DOCUMENTS - 7
has-background-info has-text-white has-background-warning has-background-warning
Description:
The #2102 Dovetail Triangular Tie is used to anchor masonry to concrete with the #1304 dovetail slot or with a wedge anchor.
Dimensions:
| Dovetail | Triangle Diameter | Triangle Sizes |
|---|---|---|
| 12 gauge x 7/8' with 5/16' hole | 3/16' or 1/4' | 3'x3' 4'x4' 5'x5' 6'x6' 7'x7' 7'x9' Custom sizes available |
FINISHES:
- Mill Galvanized
- Hot Dip Galvanized
- Stainless Steel
Da 101 dovetil anchors
Designed to anchor masonry to concrete. Used with DA100 Dovetail Anchor Slot.
Da720 series dovetail triangular ties
Designed to anchor masonry to concrete. Used with DA100 Dovetail Anchor Slot.
Da904 continuous channel anchor
Designed to anchormasonry to concrete, block, brick or Steelcolumns..
Da918 series channel anchor triangular
Designed to anchormasonry to astructure. Used with DA901, DA902, DA903 or DA904 Channel Anchor Slots.
Da 207 Mssa Veneer Anchor screw on straps
Designed to anchor masonry to a structure. Used with DA700 Triangular Ties or DA750 Trapezoid Ties.
Da210X Veneer Anchor Screw on Plates
Designed to connect masonry veneer to metal stud framed structural backings.
Da213 Veneer Anchor (Plates and Pintles)
Designed to anchor masonry to a structure accommodation rigid insulation up to and including 3 inches (75mm).
Da990 Corrugated Wall Ties
Designed to anchor masonry to a structure or to tie multi wythe walls. Use in residential construction only.
Da213 seismic Veneer Anchor Plates
Designed to anchor masonry to a structure accommodation rigid insulation upto 3inchers (75mm) thick..
Dovetail Slot Ties Track
Da 213s Seismic Veneer Anchor Plates
Dovetail Slot Ties Game
Designed to anchor masonry to a structure accommodation rigid insulation with provision for holding joint reinforcement ind the veneer.
